Hot Plate Analgesia Meter FM-HAM-A100 Catalog
Overview
Hot Plate Analgesia Meter FM-HAM-A100 is a specialized instrument designed to maintain a precise temperature range of 50°C to 55°C, ensuring stable conditions for accurate testing. Using a reliable heat exposure method, it delivers consistent and repeatable results across multiple trials. Specifically developed for studies involving mice and rats, this meter is ideal for small laboratory animals. As an efficient research tool, it saves valuable time during drug testing and analgesic evaluation. Widely recognized as a trusted laboratory standard, it is extensively used in pain threshold and analgesia research worldwide.
Specifications:
| Temperature Maintain | 50°C to 55°C |
| Ambient Temperature | 60℃ |
| Temperature display accuracy | 0.01℃ |
| Temperature control error | 0.01℃ |
| Timing range | 0.01 to 6000sconds |
| Time error | 0.01s |
| Display mode | 7-inch-high-definition capacitive touch screen display, all indicators are displayed simultaneously |
| Display content | actual temperature setting temperature pain threshold time number of foot lifts perpetual calendar |
| Maximum memory data | 100groups |
| Plexiglass cylinder | 220mm |
| Time control mode | panel key, foot switch and remote-control switch |
| Data interface | one USB interface, one RS 232serial interface |
| Power Consumption | 1200 W |
| Hot plate diameter | 190mm |
| Dimension (LxWxH) | 395x280x380 mm |
| Net Weight | 12 KG |
| Gross weight | 15 KG |
Features:
- Accurate Pain Sensitivity Measurement
- Controlled Temperature Range
- Quick Analgesia Screening
- Behavioural Response Detection
- Animal-Friendly Design
Applications:
Hot Plate Analgesia Meter FM-HAM-A100 is used to evaluate pain response and analgesic effects in small laboratory animals like mice and rats. It provides researchers with a reliable method to measure pain threshold through behavioural responses such as paw lifting and licking.
