Specifications

Dynamic range	Five orders of magnitude
Linear dynamic range	R > 0.995
Processing time	≤3 seconds/sample
Light sources	Blue LED Green LED
Excitation filters	Blue 460±20 nm Green 525±20 nm
Emission filters	Blue 525 to 570 nm Green 575 to 640 nm
Detector	Photodiode: measurement capability from 300 to 1000 nm
Repeatability	<1.5%
Stability	<1.5%
Sensitivity	dsDNA: 0.5 ng/ml
Dimension (W×D×H)	194 × 155 × 72.5 mm
weight	0.4 kg

Features

• Simple operation with 4.3-inch touch screen, small and easy to use
• Accurately quantifies DNA, RNA, and protein in <3 seconds per sample
• High sensitivity with lowest DNA detection limit of 0.5 ng/ul
• Two optical channels equipped with two fluorescence channels for macromolecule quantitation in one detection
• Blue and green dual fluorescence channels
• Linear dynamic range with five orders of magnitude
• It can save at most 1,000 data and output data by USB port

Applications

• Ideal for processing scarce and difficult samples, for low quantity of DNA, RNA, or protein after extraction, also, in expensive experiments: qPCR, PCR cloning, transfection, the next generation sequencing and etc. Applied for Rhodamine detection, Cy-3 fluorescence labeling detection, RFP gene detection, Cell activity position detection.

Accessories

• Accessories no	Accessories name
  1.	Adapter for 0.5ml qPCR tube

Accessories Optional

• Accessories no	Accessories name
  1.	Adapter for 0.2ml qPCR tube
  2.	Printer

Fluoroscence Channel

• Blue and green channels
  For blue fluorescence channel:
  Light source: Blue LED
  Excitation wavelength: 460±20 nm
  Emission wavelength: 525 to 570 nm (45 nm)
  For green fluorescence channel:
  Light source: green LED
  Excitation wavelength: 525±20 nm
  Emission wavelength: 575 to 640 nm (65 nm)
