Fison Laboratory Spray Dryer FM-SDM-A100 dries liquid feed at 1500 to 2000 ml/h, with an inlet air temperature of 30 to 280 °C and an outlet air temperature of 40 to 120 °C. This lab spray dryer machine holds temperature within ±1 °C and dries the spray in 1.0 to 1.5 s, with the feed pump adjustable from 30 to 2000 ml/h. It turns aqueous solutions, emulsions and suspensions into dry powder.
$8,910.00
| Max capacity | 1500 to 2000 ml/h |
| Temperature range of Inlet air | 30℃ to 280℃ |
| Temperature range of outlet air | 40℃ to 120℃ |
| Precision of temperature | ± 1 ℃ |
| Dryer time | 1.0 to 1.5 s |
| Speed of squirmy pump | 30 to 2000 ml/h |
| Consume of dryer air | 0 to 330 m3/h, max pressure: 686 Pa |
| Consume of spray air | 0 to 4.2 m3 /h, spray pressure: 2 to 5 bar |
| Spray system | Two-fluid spray atomization structure with standard 0.7mm nozzle options of 0.5/1.0/1.5/2.0/2.5 mm |
| Spray direction | Downwards co-current |
| Power Consumption | 3.5 kW |
| Dimensions | 650 × 500 × 1550 mm |
| Weight | 150 kg |
Laboratory Spray Dryer FM-SDM-A100 is used in bioengineering, food science, biology, chemical, pharmaceutical, and materials science laboratories to convert aqueous solutions, emulsions, and suspensions directly into uniform powder for sample preparation and drying research.
Fison Laboratory Spray Dryer atomizes liquid feed into a heated drying chamber, with inlet air temperature from 30°C to 280°C and maximum capacity from 1500 to 2000 ml/h. Inlet and outlet air temperatures are tracked to close precision, which keeps moisture removal consistent from batch to batch. As a laboratory spray dryer machine, it converts liquid feed into dry powder through controlled hot-air evaporation.
