Liquid to Liquid Thermal Shock Chamber FM-LTC-A100
Liquid to Liquid Thermal Shock Chamber FM-LTC-A100 offers a compact 2.6-liter test space designed for precise thermal cycling of small components. It supports a wide temperature range from -65°C to +150°C, enabling rigorous testing under extreme thermal conditions. Our chamber automatically moves the specimen basket between hot and cold baths for accurate thermal transitions. Its 7-inch color touch screen provides intuitive control and real-time monitoring, ensuring user-friendly operation.
Specifications
| Test Space Volume | 2.6 L |
| Test Space Temp. Range | -65 to +150 ℃ |
| Liquid Medium | Fluorocarbon Oil |
| Hot Bath Temp. Range | +70 to +200 ℃ |
| Cold Bath Temp. Range | -80 to 0 ℃ |
| Temperature Constancy | ±0.3 to ±1.0 ℃ |
| Temperature Homogeneity | ±0.5 to ±2.0 ℃ |
| Specimen Transfer Time | 10 sec (Time of transfer between hot and cold baths) |
| Temperature Recovery Time | Within 5 mins |
| Cooling Method | Water-Cooled |
| Power Supply | AC380V ±10%, 50Hz, 3/N/PE |
| Test Space Dimension (W × D × H) | 120 × 120 × 180 mm |
| Inside Bath Dimension (W × D × H) | 250 × 350 × 400 mm |
| External Dimension (W × D × H) | 1100 × 1400 × 2000 mm |
Features
- Modular construction
- User-friendly software
- Observation window
- Ethernet/USB interface
- Independent intelligent protection
- Sealed structure
Applications
- Liquid to Liquid Thermal Shock Chamber FM-LTC-A100 is used to evaluate the durability and reliability of materials or components and is widely used in medical devices, materials research, automotive industry, aerospace and defense, electronics, and semiconductors.
Accessories
Fluorocarbon oil
Specimen basket
