Thermal Shock Test Chamber FM-TSC-A101
Thermal Shock Test Chamber FM-TSC-A101 offers a 100-liter test space, ideal for conducting rapid and precise thermal cycling tests. It operates within a wide temperature range of -40°C to +150°C, enabling accurate and consistent temperature transitions. Its automated maintenance reminders and integrated fault recording software ensure timely servicing and quick diagnostics to minimize downtime. Our chamber features a 7-inch color touchscreen for intuitive control and real-time system monitoring.
Specifications
| Test Space Volume | 100 L |
| Temp. Range | -40℃/-55℃/-66℃ to +150 ℃ |
| Max. Specimens Weight | 30 kg |
| Hot Chamber Temp. Range | +50 to +200 |
| Cold Chamber Temp. Range | -80 to +70℃ |
| Temp. Constancy | ±0.3 – ±1.0 ℃ |
| Temp. Homogeneity | ±0.5 – ±2.0 ℃ |
| Recovery Time | Less than 5 min (on Air Outlet) |
| Cooling Methods | Water-cooled |
| Power | AC380V ±10%, 50Hz, 3/N/PE |
| Test Space Dimension (W × D × H) | 500 × 500 × 400 mm |
| External Dimension (W × D × H) | 1000 × 2400 × 2250 mm |
Features
- Modular construction
- Customer-friendly interface
- Eco-friendly refrigeration control
- Ethernet and USB connectivity
- Independent sensors
- Long defrosting cycle
Applications
- Thermal Shock Test Chamber FM-TSC-A101 is widely used in medical devices, the electronics industry, the automotive industry, aerospace and defense, consumer electronics, and the energy sector.
Accessories
2 Stainless steel shelves
