Plant Root Scanner FM-PRS-A100 Catalog
Overview
Plant Root Scanner FM-PRS-A100 offers high precision with less than 4% error in root length measurement. It also achieves under 5% RSD in root nodule identification. It uses advanced software encryption to ensure secure storage and protection of sensitive research data. Our scanner features a personalized, user-friendly data display for easy observation. It provides one-click tabular data export, allowing easy and efficient saving and sharing of root and nodule analysis results.
Specifications:
| Scanning Range | 215.9 × 355.6 mm |
| Root Tip Accuracy Error | < 5% |
| Root Length Accuracy Error | < 4% |
| Projection Area Accuracy Error | < 4% |
| Surface Area Accuracy Error | < 4% |
| Average Diameter Accuracy Error | < 0.04% |
| Volume Accuracy Error | < 4% |
| Number of Root Nodules Error | < 5% |
| Root Nodule Identification Error | RSD < 5% |
| Overall Parameters | Total root lengthTotal number of root tipsTotal overlap quantityNumber of lateral root bifurcationsMean diameter of root systemVolumeProjection areaSurface area |
| Topology Analysis Parameters | Root length at all levelsAverage diameter of roots at all levelsRoot surface area at all levelsRoot projection area at all levelsNumber of root connections at all levelsRoot volume at all levels |
| Root Nodule Analysis Parameters | Number of root nodulesRoot nodule areaRoot nodule volume |
| Connection Analysis Parameters | Total average length of each segmentTotal average projected area of each root segmentOverall average angle of each root segmentTotal average surface area of each root segmentTotal average volume of each root segmentTotal average diameter of each root segment |
| Dimension (L × W × H) | 576 × 297 × 118 mm |
| Weight | 10 Kg |
Features:
- Professional root nodule analysis
- One-click multi-parameter analysis
- Automated large-scale root and nodule data analysis
- Intelligent correction and precise data output
- Automatic outlier removal
- Automatic data saving
- Integrated research app and cloud platform
Applications:
Plant Root Scanner FM-PRS-A100 is widely used in agricultural research labs, universities, plant science research centers, soil and environmental studies to assess root-soil interactions, and biotech labs.
