Freeze Dryer FM-FD-C101 is designed with a 1550 in² shelf area, ensuring efficient results. It offers a precise temperature range of−20 °C to −30 °C, ensuring optimal drying efficiency. It features an advanced cooling system that provides efficient heat dissipation, maintaining stable temperatures. Our freeze dryer features an LCD for real-time monitoring of key parameters.
$7,481.00
| Fresh product (batch) | 22–35 lbs / batch |
| Fresh product (annually) | 6000 lbs / annually |
| Dried product (batch) | 3.2–9.9 lbs (15–45 % solid matter) |
| Dried product (annually) | 900–2700 lbs (15–45 % solid matter) |
| Working principle | Sublimation |
| Fresh product | Frozen before sublimation |
| Product cooling | In the machine or in your refrigerator |
| Usable shelf area | 1550 in² |
| Number of shelves | 7 |
| Shelf spacing | 1.4 in (35.6 mm) |
| Shelf dimension | 9.84 × 26.38 in |
| Tray dimension | 9.64 × 12.4 × 0.98 in |
| Number of product trays | 12 pieces |
| Vacuum pump | Double stage |
| Ultimate vacuum level | 15 Pa |
| Refrigeration compressor | Full hermetic |
| Refrigerant | Environment friendly |
| Product freezing temperature | −20 °C to −30 °C |
| Cold trap freezing temperature | −30 °C to −40 °C |
| Cooling way | Air cooling |
| Heating | By electricity |
| Control system | Smart control |
| Power consumption | 3500 W |
| Power supply | 115 / 220 V, 50 / 60 Hz, single phase |
| Dimension | 1480 × 860 × 1450 mm |
| Weight | 305 kg |
Shelves
Trays
Vacuum pump
