UV Trans-illuminator FM-UVT-A101
UV Trans-illuminator FM-UVT-A101 offers a single 302 nm wavelength, ideal for clear visualization of fluorescent DNA stains. This features adjustable light intensity, allowing for precise control during fluorescence imaging. It includes a standard UV shield to protect users from harmful UV exposure. Our transilluminator automatically shuts down to prevent overheating and ensure device protection.
Specifications
| Transmission Area | 215×265mm |
| Wavelength | Single wavelength: 302nm (peak) |
| Light Intensity | Adjustable |
| Surface | Toughened glass surface |
| Dimensions(L×W×H) | 330×280×115mm |
| Weight | 7kg |
Features
- Efficient UV filter system
- Advanced gel viewing options
- Reduces sample damage effectively
- Precise UV wavelength control
- Lightweight and transportable
Applications
- UV Trans-illuminator FM-UVT-A101 is primarily used in molecular biology and biochemistry for visualizing nucleic acids or proteins stained with UV-sensitive dyes. It is commonly applied in laboratories for gel electrophoresis, DNA/RNA analysis, and protein identification.
