Auto Hematology Analyzer FM-AHA-A100
Auto Hematology Analyzer FM-AHA-A100 provides rapid and precise blood sample analysis with a high throughput of 60 samples processed per hour. Configured with a 10.4-inch color touch LCD screen, providing an intuitive and user-friendly interface for easy operation. Our analyzer generates three histograms that provide graphical representations of cell size distribution (RBC, WBC, PLT).
Specifications
| Throughput | 60 Sample per hour |
| Sample Volume | Prediluted: 20µL, Whole Blood:9.8 µL |
| Principle | Electrical Resistance for counting WBC,RBC & PLT |
| Parameters | WBC,LYM#,MID#,GRA#,LYM%,MID%,GRA%, RBC,HGB,MCHC,MCH,MCV, RDW-CV,RDW-SD,HCT,PLT,MPV,PWD,PCT,P-LCR & Histogram for WBC,RBC & PLT |
| Temperature Range | 15 to 35 °C |
| Humidity | ≤80% |
| Power Supply | AC110 TO 220 v 50/60 Hz |
| Dimension | 436 × 363 ×367 mm |
| Weight | 18 Kg |
Features
- Large LCD touchscreen display with advanced eye protection
- Stimulate 20 parameters with accurate result
- Integrated with 2 counting modes whole blood and prediluted
- Equipped with a built-in thermal printer
- Supports external printer connection
- Utilizes the electrical impedance method
- Fully intelligent blockage removal and alarm functionality
- Provides both automatic and manual calibration options
- Compatible with the LIS interface
Applications
- It is used to count leucocytes, red cells and platelets in blood and also determine hemoglobin and hematocrit levels.
