Electronic Liquid Densitometer FM-EDM-B100
Electronic Liquid Densitometer FM-EDM-B100 offers measurement accuracy of ±0.0001 g/cm³ using the U-tube oscillation method combined with Peltier temperature control. This intelligent density meter supports real-time sample viewing, automatic injection, rinsing, and drying, ensuring precise and repeatable results across a wide range of liquids. Designed for high-efficiency labs, it is ideal for applications in food, pharmaceuticals, chemicals, and alcohol content analysis.
Specifications
| Measurement repeatability | ±0.0001 g/cm³ |
| Measurement resolution | 0.0001 g/cm³ |
| Density measurement range | 0.0001 to 1.9999 g/cm³ |
| Measurement mode | Density (g/cm³), Concentration% (mass fraction), Baumé, etc. |
| Temperature resolution | 0.1 °C |
| Temperature control range | 15 to 35 °C |
| Sampling capacity | <6 mL |
| Observation method | Real-time graphic acquisition |
| Calibration method | Dry air / Distilled water |
| Sample library | Group of 100 |
| Data storage | Group of 100 |
| Display mode | 7-inch colour LCD touchscreen |
| Output interface | RS232, USB (optional), USB flash drive (optional) |
| Printer model | RD TH-325C (optional) |
| Power supply | 110 to 240 V, 50/60 Hz, 100 W |
Features
- Compact benchtop design
- Calibration via dry air or distilled water
- Optional printer and USB output for result backup
- Compatible with external thermal printer
Applications
- Suitable for accurate liquid density and concentration testing in food, beverages, alcohol, chemical industries, pharmaceuticals, and R&D laboratories.
Frequently Asked Question
1: How does FM-EDM-B100 ensure high-sensitivity accuracy?
FM-EDM-B100 offers ±0.0001 g/cm³ repeatability using U-tube vibration and Peltier temperature control for precise readings.
2: How does FM-EDM-B100 detect bubbles or impurities?
It uses real-time graphic acquisition to monitor sample flow and catch air bubbles or inconsistencies during injection.
3: Can FM-EDM-B100 convert density into concentration formats?
Yes, FM-EDM-B100 supports conversions to mass fraction and Baumé scales using its built-in measurement modes.
4: Is FM-EDM-B100 suitable for GLP-compliant labs?
It stores 100 methods and test records and supports RS232 and USB output, aligning with data traceability needs.
5: What makes FM-EDM-B100 ideal for fast lab workflows?
Its auto injection and quick stabilization make FM-EDM-B100 efficient for routine testing in food, pharma, and chemical labs.
