$3,362.00

Halogen Moisture Analyzer FM-HMA-A203 - Specifications

Range	4 mg to 210g
Readability	0.001g
Operating Temp	5℃ to 35℃
Pan Size	Ø100mm
Heat Source	Halogen Lamp
Temperature Sensor	PT 100
Temp. Range	40℃ to 230℃
Temperature Step	1℃
Moisture Range	0.00% to 100.00%
Moisture Readability	0.01%
Dry Residual Range	100.00% to 0.00%
Dry Residual Readability	0.01%
ATRO	0% to 999%
Temp Setting	40℃ to 230℃ By 1℃ Step
Time Setting	1 to 99min by 10 s
Number Of Storage	20
Number Of History	20
Display	7-inch touch panel
Interface	RS232/RJ45/USB
Communication Mode	Cable
Rechargeable Battery	No
Calibration	External
Function expansion	Customized
Heater power supply	220V ±15% 50HZ/, 110V±15% 60HZ 400W
Balance power supply	Input: 220V 50HZ/110V 60HZ Output:9V
Machine power supply	Input: 220V 50HZ/110V 60HZ Output:24V (Dual drive)
Operation Height	275 mm
The Chamber Height	35 mm
Host Dimension (L×B×H)	215×195×415 mm
Indicator Dimension (L×B×H)	200×75×135 mm
Gross weight	10 kg

Halogen Moisture Analyzer FM-HMA-A203 - Features

1. Halogen lamp heating mode
2. Ergonomically designed pan handle
3. 7-inch smart touch LCD display
4. Automatic sensor opening door of heating chamber
5. Displays test values as percentage of dry weight (%) / Moisture (% m) / the weight (g)
6. Weighing range: 4 mg to 210 g
7. Weighing resolution or readability: 0.001 g
8. Moisture content measuring range: 0.00 to 100.00 %
9. Moisture content resolution or readability: 0.01 %
10. Adjustable drying time and temperature
11. Memory stores up to 20 drying profiles
12. Long distance operation using smart touch panel
13. Maximum 230°C heating temperature
14. <strong>Testing Mode: </strong>
15. Auto Mode: The mode is suitable for most of the samples for common moisture analysis
16. Soft Mode: Some fusible and volatility things can choose this mode
17. Fast Mode: Some stable and thermostable things can choose this mode
18. Stainless steel drying pan is quick and easy to clean
19. Manual setting for temperature and time
20. Wireless communication mode using 10,000 mAh battery and RS232/RJ45/USB interface

Halogen Moisture Analyzer FM-HMA-A203 - Applications

• Suitable for the testing and analysis of samples of materials such as wood, pellets, biomass, granules, feed, food products and pastes. Also, designed for food, plastics and chemical moisture analysis.

Halogen Moisture Analyzer FM-HMA-A203 - Accessories

• Accessories	Quantity
  Wind Cover	1 piece
  The sample pan holder	1 piece
  Tray handle	1 piece
  Aluminium sample pan	1 set of 80pcs
  100g standard weight	1 piece
