Specifications

Maximum speed	6000 rpm
Maximum RCF	5000 × g
Rotor capacity	100 ml × 4
Temperature increment	≤ 10℃ (running 20 minutes)
Speed accuracy	± 20 rpm
Noise level	≤ 55 dB
Centrifugation time	1s to 99 min continuous /timed centrifugation
Power supply	AC 220 V/50 Hz, 12 A
Weight	65 kg
Dimension (L×W×H)	433 × 580 × 402 mm

Features

• Compact and robust benchtop design, LCD display with microprocessor controlled system
• Spin time 6000 rpm with 5000 ×g Rcf
• Swing rotor includes 4 aluminum sleeves for 100 ml tubes
• Driven by AC frequency conversion motor
• Compasses 9 different rate selection modes and 10 different operation modes for programming
• Large assortment of rotors, buckets and adaptors for micro tubes and all sizes of tubes
• Two optional work setting type: run start and interval run time settings can be switched
• Double lock rod design of door with magnetic and electric locks
• Parameters altering function without downtime
• Furnished with unique air flow design and anti-vibration structure to minimize heat and noise generation
• Automatic lid release and vivid end alarm for easy retrieval of sample

Applications

• Ideal for general laboratory applications, including biological sample separations of cellular materials. Also, used for clinical applications of PRF, PRP and lipid cell and stem cell isolation. Applied for gentle, soft spin-down or washing of primary cells & cell line.

Standard Rotor Selection

• Rotor name	Rotor capacity	Max speed	RCF
  Swing bucket rotor 1	4×100ml（Round hanging cup）	5000 rpm	4472 ×g

Standard Adatpter Selection

• Adapter 1	4×100ml
  Adapter 2	4×50ml
  Adapter 3	12×15ml（Bottom tip with cover）
  	12× urinary sediment tubes
  Adapter 4	16×10ml/15ml
  	16×Vacuum blood tube(high)
  Adapter 5	16×Vacuum blood tube(short)

Optional Rotor Selection

• Angle rotor	12 × 15 ml	6000 rpm	5000 ×g
  ELISA plate rotor	96 holes × 2	4000 rpm	2253 × g
